Designing Photonic Crystal Fibers for OAM Modes : Photonic crystal fibers (PCFs) represent a class of optical fibers that incorporate periodic microstructures—typically arrays of air holes in a silica matrix—to guide light through modified refractive index profiles. These structures offer highly tunable modal characteristics, which are essential in specialized applications such as nonlinear optics, sensing, and increasingly, in orbital angular momentum (OAM) multiplexing.
The concept of orbital angular momentum in light arises from the helical phase structure carried by certain optical beams. Unlike spin angular momentum, which pertains to polarization, OAM modes possess an azimuthal phase dependence of the form $\exp(i\ell\phi)$, where $\ell$ is the topological charge and $\phi$ is the azimuthal angle. Each OAM mode is orthogonal to the others, allowing theoretically unlimited multiplexing in optical systems. This property makes OAM modes extremely attractive for boosting the capacity of optical communication networks beyond conventional wavelength- or polarization-division multiplexing.
The surge in data demands, spurred by cloud computing, 5G/6G infrastructures, and immersive technologies, has pushed researchers to explore OAM multiplexing as a key enabler of ultra-high-capacity transmission. However, sustaining a large number of OAM modes—particularly more than 120—presents significant challenges in terms of mode purity, loss, and crosstalk.
Recent studies point to high-index rings embedded in PCFs as a promising design innovation. These rings can create effective index separations and spatial confinement necessary to maintain mode orthogonality and purity over long distances. As demonstrated in Frontiers in Physics, the use of a double-layer ring PCF achieved stable transmission of 118 OAM modes with low confinement loss, signaling a leap forward in practical deployment.
Understanding how these high-index rings function and can be engineered is central to pushing PCFs toward the next threshold of OAM mode counts, possibly exceeding 200. This article dissects the fundamental principles, contemporary approaches, technological innovations, and real-world implications of designing PCFs tailored for ultra-high OAM multiplexing.
Core Concepts and Background
Photonic crystal fibers derive their unique optical properties from the periodic arrangement of air holes running along the length of the fiber. Depending on their configuration—index-guiding or photonic bandgap—the guiding mechanism varies. In conventional PCFs, the core is formed by a missing or modified air hole in the central region, surrounded by a structured cladding. This structure alters the effective refractive index, allowing light confinement beyond what standard fibers can offer.
A critical metric in PCF design is the effective index difference between adjacent modes, denoted as $\Delta n_{\text{eff}}$. For OAM mode transmission, maintaining a sufficient $\Delta n_{\text{eff}}$ ensures minimal modal coupling and high purity. This is vital when trying to propagate over 100 OAM modes, each requiring orthogonality to avoid crosstalk.
OAM modes are characterized by their azimuthal phase and transverse intensity distribution. In optical fibers, generating and maintaining such modes necessitates rotational symmetry and tailored refractive index profiles. The use of ring-core fibers has become increasingly common, with the core shaped like a hollow cylinder rather than a solid rod. This allows the field to possess a well-defined angular momentum component, making it compatible with OAM modes.
However, simply employing a ring-core does not suffice for high OAM counts. Key enabling mechanisms include:
- High-index contrast: Introducing high-index rings—through doping with germanium, tellurium, or fluoride—provides spatial confinement for OAM modes. These rings form potential wells where specific $\ell$ modes can localize.
- Mode purity: Measured as the overlap of a given mode with its theoretical distribution, mode purity degrades with increasing OAM count unless proper separation is maintained.
- Confinement loss: As higher-order modes extend further into the cladding, confinement becomes critical. High-index rings can trap these modes, reducing leakage and loss.
From a theoretical standpoint, high-index rings enhance the modal separation by modifying the eigenvalue problem associated with the wave equation in cylindrical coordinates. This tailoring can be understood by solving the Helmholtz equation for structured dielectric environments, where the refractive index is radially dependent. Simulations using finite element or beam propagation methods reveal that properly spaced high-index rings significantly suppress intermodal coupling, especially for adjacent $\ell$ values.
The foundational framework for OAM modes in PCFs is further explored in this detailed study, which outlines how optimized refractive index profiles can boost OAM performance. Other contributions, such as the overview in Optica-OPN, emphasize the evolution of PCFs from early prototypes to complex, functional systems capable of supporting quantum-level communication protocols.
Furthermore, the work on generation and fidelity of OAM modes within fibers, including experimental demonstrations, is thoroughly discussed in Frontiers in Physics. These studies validate the necessity of refractive index control, phase alignment, and structural precision for large-scale OAM transmission.
With this background in place, the article next delves into the specific architectures and approaches that have emerged as top contenders in achieving the >120 OAM mode threshold, with a focus on design trade-offs and performance metrics.
Tools, Technologies, and Approaches
Designing photonic crystal fibers capable of supporting over 120 OAM modes necessitates precision engineering and innovation across several fronts—material selection, index profiling, structural geometry, and fabrication fidelity. The following five approaches have emerged as the most effective, each offering distinct trade-offs and technical advancements.
Double-Layer Ring PCF
One of the most successful designs to date is the double-layer ring photonic crystal fiber, which uses two concentric high-index rings doped with elements such as germanium or fluoride. These rings create multiple potential wells along the radial axis, allowing for the localization of numerous distinct OAM modes. This design has demonstrated support for 118 OAM modes with high mode purity and low confinement loss, making it a practical candidate for real-world deployment.
What distinguishes this configuration is the fine-tuned refractive index gradient across the core and cladding, which minimizes intermodal coupling while maintaining low bending loss. The inner ring typically confines low-order modes, while the outer ring accommodates higher-order ones, effectively creating a hierarchy of modal support zones.
As detailed in Frontiers in Physics, simulations and experimental verifications confirm that the double-layer architecture suppresses mode degeneration and enhances purity. This makes it particularly suitable for dense OAM multiplexing where crosstalk must be meticulously controlled.
Large Effective Mode Area Silica PCF
A complementary approach focuses on enlarging the effective mode area through a silica-based PCF with an optimized ring thickness and spacing. This method allows for broader confinement of light, reducing nonlinear effects and improving power handling, which are critical in high-data-rate applications. These fibers have successfully demonstrated the support of 134 OAM modes.
The large mode area strategy works by reducing the overlap between adjacent modes, which enhances spatial orthogonality and therefore modal purity. It also improves bending resistance—a major limitation in high-OAM fibers—by dispersing stress over a wider region.
According to a recent study from City University of Hong Kong (2024 report), this design strikes a balance between scalability and practicality, enabling a higher count of usable OAM modes without significant fabrication complexity.
Nested Three-Ring-Core PCF
The nested ring-core design introduces a novel multi-layered structure with three concentric guiding regions. Each ring is engineered to support a distinct subset of OAM modes, effectively partitioning the modal space into isolated domains. This architecture achieves excellent isolation between mode families and facilitates ultra-high OAM transmission—surpassing 120 modes.
This concept is structurally more complex but provides an effective solution to modal crosstalk. Each nested ring operates almost as an independent waveguide, with tailored index profiles ensuring minimal intermodal interaction.
The publication on CityU’s photonics archive describes how each layer’s refractive index and thickness are calibrated using eigenmode solvers to maximize mode discrimination. This design also shows resilience against fabrication defects, owing to its distributed confinement mechanism.
Polymer-Based PCF for Terahertz Applications
Moving beyond silica, polymer-based PCFs have recently emerged as a compelling solution, especially for terahertz (THz) band applications. These fibers exhibit ultra-low loss and excellent flexibility, supporting an extraordinary 242 OAM modes as reported in ScienceDirect. Their utility lies in low-cost, customizable manufacturing and high modal capacity in the THz frequency range, where conventional silica fibers fail due to absorption.
Polymers allow for greater freedom in doping and structural manipulation, opening pathways to 3D-printed or lithography-based PCFs with highly complex internal geometries. These fibers are expected to be pivotal in short-range, high-bandwidth communication systems, such as chip-to-chip interconnects and secure intra-data center networks.
Despite these advantages, polymer fibers face challenges in thermal stability and long-haul propagation, which limit their application scope. However, for localized high-density communication systems, they are unmatched in modal performance.
Rectangular Air-Hole PCF
An unconventional yet effective approach utilizes rectangular air holes instead of the traditional circular or elliptical ones. This modification enhances the refractive index contrast along specific axes, increasing the birefringence and, consequently, the mode separation. Although this type supports a relatively lower OAM mode count—about 50 modes—it excels in applications requiring precise modal filtering or hybrid OAM-polarization multiplexing.
A notable study published in SCIRP demonstrates how asymmetry in the air-hole structure contributes to improved confinement and reduced degeneracy between neighboring modes. These fibers are also easier to fabricate using current drilling and etching technologies, making them cost-effective for medium-scale deployments.
While not the top choice for ultra-high OAM count systems, rectangular air-hole PCFs play a crucial role in modular network architectures where different fibers are optimized for different modal bands.
Taken together, these five design philosophies showcase the diversity of approaches available for scaling up OAM multiplexing in optical fibers. Each method carries distinct trade-offs in fabrication complexity, spectral bandwidth, and loss characteristics, but all contribute meaningfully to the overarching goal of creating PCFs capable of handling more than 120 OAM modes in real-world settings.
In the next section, we will explore recent experimental validations and technology milestones that have moved these designs from lab-scale concepts to practical deployment.
Recent Developments in High-OAM Photonic Crystal Fibers
Over the past few years, the pursuit of supporting an ultra-large number of orbital angular momentum (OAM) modes in photonic crystal fibers (PCFs) has transitioned from theoretical modeling to tangible experimental demonstrations. These recent advancements have primarily focused on optimizing refractive index architectures, refining fabrication techniques, and validating performance metrics such as mode purity, confinement loss, and bandwidth scalability. This section highlights the most significant developments that have shaped the current frontier of high-OAM PCF research.
Double-Layer Ring PCF Achieving 118 OAM Modes
A landmark achievement in the field has been the realization of a double-layer ring PCF supporting 118 OAM modes with low confinement loss and excellent mode purity. As detailed in Frontiers in Physics, this design strategically places two concentric high-index rings in the cladding, creating dual confinement zones. This geometry results in a quasi-bandgap effect that helps suppress undesired mode coupling and enhances the fidelity of OAM transmission.
One of the key contributions of this study lies in the empirical verification of simulated mode fields. By using near-field scanning techniques and interferometric analysis, the researchers could identify OAM mode profiles with topological charges ranging from $\ell = \pm1$ to $\ell = \pm59$. Furthermore, confinement losses remained below 0.01 dB/m, even for high-order modes, indicating a robust guiding mechanism.
The experimental results corroborate earlier simulations and confirm the viability of the double-layer architecture not only for laboratory-scale experiments but also for practical communication systems where high modal counts and long-distance propagation are necessary.
Silica PCF Designs Supporting Over 130 OAM Modes
Another crucial milestone was achieved with silica-based PCFs engineered to support 134 OAM modes. These designs leverage a large effective mode area, paired with finely tuned ring thicknesses and spacing to reduce nonlinearity and intermodal coupling. As demonstrated in the 2024 publication from City University of Hong Kong (source), the fiber shows impressive performance in both simulation and preliminary experimental setups.
The main innovation in this work is the layered doping process, where regions of different refractive indices are doped sequentially to create precise index steps. This method avoids abrupt changes that could otherwise introduce scattering centers and confinement issues. Additionally, the design improves bending tolerance—an often overlooked but critical factor for real-world deployment.
Interestingly, despite the complex fabrication process, the researchers report excellent reproducibility between fabricated samples, suggesting that the design could be scalable for industrial applications.
Nested and Graded-Index Ring-Core Innovations
Nested ring-core PCFs and those with graded-index rings have also demonstrated notable improvements in OAM mode support, especially in terms of purity and stability. These designs introduce radial refractive index variations that better match the natural field distributions of OAM modes, thereby reducing scattering and mode overlap.
A particularly relevant study published in Optics Communications details how graded-index profiles help in mitigating crosstalk in densely packed mode groups. Here, a smooth transition between refractive indices minimizes interface scattering and effectively maintains orthogonality between closely spaced OAM channels.
These graded and nested structures show enhanced performance when evaluated using overlap integrals and modal discrimination functions, which assess how well each mode retains its unique spatial characteristics under perturbations such as bending or thermal fluctuations.
Broader Trends and Validation Methods
Recent work has also focused on the standardization of validation protocols for OAM mode support. Common tools now include near-field scanning for field profiling, interferometric phase analysis for topological charge validation, and spectral loss characterization. These methods have been critical in transitioning PCFs from theoretical feasibility to verified performance.
Moreover, there is a noticeable trend toward using hybrid modeling environments that combine beam propagation methods (BPM), finite-difference time-domain (FDTD), and eigenmode expansion to provide comprehensive predictions of mode behavior. These simulations are increasingly corroborated by experimental data, showing the maturity of PCF design techniques.
Together, these developments have pushed the state of the art in OAM-compatible PCFs from dozens to well over a hundred stable modes. The next frontier lies in addressing scalability and integration challenges, which will be discussed in the upcoming section on open questions and technical barriers.
Challenges and Open Questions
Despite the considerable strides made in the design and realization of high-OAM photonic crystal fibers (PCFs), several technical and practical challenges persist. These hurdles must be overcome to transition from promising laboratory prototypes to scalable, cost-effective solutions ready for integration into global communication infrastructures. The following subsections outline the most critical challenges, drawing upon recent literature and expert commentary.
Fabrication Complexity and Reproducibility
Designs that incorporate high-index rings, nested cores, or graded-index profiles often demand extreme precision during fabrication. Small deviations in dopant concentration, layer thickness, or symmetry can dramatically alter modal characteristics. Achieving the necessary sub-micron accuracy over long fiber lengths is non-trivial and remains a significant barrier to mass production.
As highlighted in Advanced Photonics, many experimental PCFs that demonstrate remarkable OAM mode support are still fabricated in university or research lab settings, using controlled environments that are not easily replicable at scale. This gap underscores the need for improved manufacturing techniques, such as 3D nano-printing or preform stack-and-draw optimization, to translate theoretical designs into consistent real-world fibers.
Moreover, the use of multiple dopants or layers can introduce thermal expansion mismatches, leading to internal stress during cooling or spooling. These mechanical instabilities can compromise long-term reliability and make it difficult to produce long lengths of fiber without structural defects.
Confinement Loss and Mode Purity at High OAM Counts
As the number of supported OAM modes increases, ensuring low loss and high purity becomes exponentially more difficult. High-order modes are more susceptible to scattering and typically exhibit greater radial extension into the cladding, increasing the likelihood of leakage or coupling to other modes. This results in a trade-off between increasing the OAM mode count and maintaining acceptable performance metrics.
The recent study from CityU (2024 paper) provides compelling evidence that even well-designed structures begin to show degradation in confinement loss and purity beyond 130 OAM modes. It suggests that new materials with lower absorption coefficients or advanced confinement strategies—such as photonic bandgap layers or quasi-crystalline geometries—may be required to push beyond this threshold.
Additionally, the definition and quantification of “mode purity” remain loosely standardized across studies, with different groups using different metrics such as overlap integrals, modal power ratios, or spectral phase fidelity. A more unified benchmarking system would help clarify what constitutes a viable high-mode-count PCF.
Doping vs. Loss Trade-Offs
High-index doping is central to many advanced PCF designs, but it introduces its own complications. Doping materials like germanium or tellurium increase the refractive index contrast, which is essential for tight mode confinement and mode separation. However, these same dopants also tend to raise scattering and absorption losses, particularly at telecom wavelengths (1.3–1.55 μm).
This trade-off becomes more pronounced as designers attempt to optimize for both high mode count and low attenuation. For instance, in Frontiers in Physics, the authors of the double-layer ring PCF noted that while the outer high-index ring allowed for higher $\ell$ modes, it also contributed disproportionately to total confinement loss, particularly in the 1550 nm band.
Innovative material blends and graded doping profiles may offer a way forward, but they come with increased fabrication complexity and often require bespoke deposition or extrusion equipment.
Interoperability and Cost Constraints
Even if all technical challenges were solved, another formidable hurdle lies in integrating high-OAM PCFs into existing communication infrastructure. Most current telecom systems are optimized for single-mode or few-mode fibers, and deploying PCFs with specialized modal properties would necessitate changes in amplifiers, connectors, and switching elements.
In their market review, Research Nester emphasizes that the cost per kilometer for complex PCFs is still significantly higher than standard single-mode or multi-mode fibers. Until these costs come down—either through manufacturing scale or process innovation—it is unlikely that PCFs will see widespread deployment beyond research and niche applications.
There is also the question of backward compatibility. Current telecom systems would need hybrid converters or mode multiplexers to interact with OAM-PCFs, potentially adding latency and cost. Efforts are underway to develop seamless OAM-mode compatible routers and detectors, but they remain in early development stages.
Standardization and Regulatory Considerations
As PCFs become more integral to high-capacity networks, standardization will be key. Currently, there is no unified standard for OAM mode enumeration, measurement, or purity thresholds. This lack of consensus hampers collaborative research and slows industrial adoption. Regulatory bodies like the ITU or IEEE may eventually provide such frameworks, but that effort will require extensive cross-disciplinary input from fiber designers, network architects, and material scientists.
Collectively, these challenges form the basis of ongoing research efforts and commercial evaluation. Solving them will not only advance the performance of OAM-capable PCFs but also catalyze their adoption across domains ranging from classical telecom to quantum networking.
Opportunities and Future Directions
As the field of photonic crystal fibers (PCFs) continues to evolve, several compelling opportunities are emerging that extend far beyond simply increasing the number of orbital angular momentum (OAM) modes. These forward-looking directions reflect a convergence of material science, computational design, and advanced fabrication, pointing toward a future where high-OAM PCFs play a central role in next-generation communication, sensing, and quantum systems.
Pushing OAM Mode Counts Beyond 200
With experimental success already surpassing 130 OAM modes, the next major benchmark is the reliable support of more than 200 distinct modes. Research such as that published in ScienceDirect demonstrates that this goal is not only feasible but already within sight through polymer-based PCF designs. These fibers, which leverage ultra-low-loss polymer matrices and large air-hole lattices, have shown the capacity to support 242 OAM modes in the terahertz band.
To translate these results into the telecom regime, advances in hybrid materials—such as chalcogenide-doped glasses or silicon-polymer composites—will be essential. These materials allow high refractive index contrast without incurring excessive absorption losses, making them ideal candidates for the next wave of OAM-PCF development.
Moreover, the use of multi-core PCFs, where each core is optimized for a specific OAM band, presents an elegant strategy for parallelizing mode capacity without exacerbating crosstalk or confinement challenges. The scalability of this approach is now being actively explored through simulation frameworks and preliminary fabrication trials.
Integration with 6G and Quantum Communication Systems
One of the most transformative opportunities lies in integrating high-OAM PCFs into emerging 6G infrastructure and quantum networks. The vast spectral and modal multiplexing potential of OAM modes aligns perfectly with the anticipated data demands of 6G applications, including real-time holography, ultra-reliable low-latency communication (URLLC), and multi-sensory immersive experiences.
In quantum communication, OAM modes offer a high-dimensional basis for encoding qubits, enabling protocols with higher security and capacity. PCFs specifically designed for quantum OAM modes are being tested in research labs to carry entangled photons over long distances without significant decoherence. These developments are supported by the fact that many high-OAM PCFs naturally exhibit low birefringence and high environmental stability—traits crucial for quantum fidelity.
The Research Nester forecast predicts a sharp rise in demand for customized fiber solutions in quantum and ultra-broadband applications, with OAM-PCFs positioned as a key enabling technology.
3D Printing and Novel Fabrication Techniques
A particularly exciting direction involves the use of additive manufacturing, especially 3D printing at the nano- and micro-scale, for creating complex PCF geometries that are impossible to achieve using traditional stack-and-draw methods. These techniques enable precise placement of dopants, subwavelength structuring, and seamless integration of multiple materials within a single fiber.
Companies and research labs are beginning to develop direct-write lithography tools that can fabricate short lengths of PCFs with extremely intricate cross-sections. These advances not only reduce prototyping time but also unlock completely new fiber architectures, such as spiral-core or fractal-guided PCFs, which may further enhance OAM stability and density.
Furthermore, the integration of photonic inverse design—where computational algorithms iteratively optimize fiber structure for target mode behavior—allows for the automatic generation of PCFs tailored to very specific application constraints. This shift from manual to algorithmic design is expected to drastically accelerate innovation in the field.
Interdisciplinary and Industry-Academic Collaboration
Realizing the full potential of high-OAM PCFs will require close collaboration across disciplines. Material scientists, photonics engineers, quantum physicists, and telecom system designers must work in tandem to ensure that fiber designs meet not only theoretical benchmarks but also industrial constraints such as cost, reliability, and interoperability.
Several consortia and academic-industry initiatives are already in place, including collaborations among European photonics institutes and Asian research universities. These efforts focus on everything from preform development to system-level integration, often supported by public funding and international standardization bodies.
Ultimately, the opportunities for high-OAM PCFs extend well beyond traditional optical fibers. They include chip-scale photonic circuits, hybrid fiber-wireless links, and sensor networks for biomedical or environmental monitoring. As the technology matures, it promises to redefine what is possible in light-based information transfer and sensing.
In the next section, we will ground these opportunities by examining real-world use cases where high-mode-count PCFs are already being deployed or tested in operational environments.
Real-World Use Cases
The transition of high-OAM photonic crystal fibers (PCFs) from theory to practice is well underway. Several cutting-edge applications already leverage their unique modal capabilities to address real-world problems in communication, data infrastructure, and sensing. These use cases not only demonstrate the technical viability of high-OAM PCFs but also affirm their growing importance in next-generation network ecosystems.
High-Capacity Data Center Interconnects
Modern data centers rely on ultra-high-throughput links between server racks, often demanding terabit-scale connections over short to medium distances. Traditional solutions based on wavelength-division multiplexing (WDM) or polarization-division multiplexing (PDM) are nearing capacity ceilings, prompting the exploration of spatial multiplexing techniques like OAM.
Photonic crystal fibers that support over 100 OAM modes offer a compelling pathway to scale up bandwidth without increasing footprint. As described in Advanced Photonics, experimental testbeds using double-ring PCFs have successfully demonstrated error-free OAM multiplexing with 100+ channels over 1 km distances, achieving aggregate data rates exceeding 10 Tbps.
These systems are particularly well-suited for structured environments where fibers can be routed with minimal bends and environmental interference. Moreover, the high isolation and low crosstalk of advanced PCFs reduce the need for complex error correction protocols, simplifying system architecture.
Long-Haul Optical Communication Links
While initially considered unsuitable for long-distance transmission due to bending and modal dispersion issues, recent advancements in PCF geometry and doping profiles have made high-OAM fibers viable for metropolitan and even long-haul networks. The key has been the use of large mode area designs with optimized refractive index gradients, which reduce both nonlinear effects and bending-induced loss.
The CityU 2024 study outlines a prototype fiber that maintains over 130 OAM modes across distances exceeding 10 km with minimal signal degradation. The potential here is significant: telecom providers could use these fibers to dramatically expand bandwidth without laying additional cables or installing more repeaters.
These high-OAM PCFs are currently being evaluated in test corridors alongside conventional fibers to compare performance under real-world stressors such as temperature fluctuations, mechanical vibration, and atmospheric pressure changes.
Mode-Division Multiplexing in Telecom Networks
Next-generation telecom networks, especially those envisioned for 6G, are expected to use multiple degrees of freedom—frequency, polarization, and spatial mode—to maximize data throughput. OAM-based mode-division multiplexing (MDM) represents a promising frontier in this effort.
Incorporating PCFs that support a high number of orthogonal OAM channels enables simultaneous transmission of multiple data streams through a single fiber core. This reduces infrastructure costs while vastly improving spectral efficiency. As demonstrated in Frontiers in Physics, PCFs tailored for OAM multiplexing have already been integrated into working MDM systems with specialized modulators and demultiplexers.
Moreover, because OAM modes can be selectively excited and detected, such systems offer greater flexibility in routing and signal management, paving the way for intelligent, adaptive network architectures.
Emerging Domains: Quantum Communication and Biomedical Imaging
Beyond classical communication, high-OAM PCFs are gaining traction in emerging domains. In quantum communication, the ability to support high-dimensional entangled states makes these fibers ideal for secure key distribution and quantum repeaters. Early-stage experiments have shown that entangled OAM photons can be transmitted over hundreds of meters using PCFs without significant decoherence.
In biomedical imaging, OAM modes are being explored to improve resolution and depth sensitivity in optical coherence tomography (OCT) and endoscopic systems. The spatial diversity of OAM beams allows for the differentiation of fine tissue structures, enhancing diagnostic accuracy. PCFs with specialized dispersion and low loss in visible to near-infrared ranges are being developed for such applications.
These use cases highlight the adaptability of high-OAM PCFs and underscore their potential to influence a broad spectrum of technological domains.
Conclusion
The journey to develop photonic crystal fibers capable of supporting over 120 orbital angular momentum (OAM) modes has ushered in a new era of optical design. Through innovations such as double-layer high-index rings, large mode area geometries, nested core architectures, and novel materials like polymers and chalcogenides, researchers have demonstrated that ultra-high modal capacity is no longer a theoretical ambition—it is a practical, experimentally validated reality.
These advances have expanded the toolkit available to optical engineers, enabling not just higher data capacities, but also improved modal purity, lower loss, and greater environmental resilience. However, challenges persist in scaling fabrication, ensuring cost-efficiency, and integrating these fibers into existing telecom infrastructures.
Looking ahead, the field is poised for further transformation through interdisciplinary collaboration, 3D-printed fiber architectures, and integration with quantum and 6G systems. As these developments mature, high-OAM PCFs are set to play a pivotal role in shaping the future of information transfer—whether through terabit-class data centers, global quantum networks, or portable diagnostic imaging devices.
The continued evolution of high-OAM PCFs will depend not only on novel designs but also on sustained investment in materials science, system-level integration, and standardization. With these elements in place, the full promise of OAM-based photonic communication may soon be realized across commercial and research applications alike.
